Description
The Mean Well 120W 48V 2.5A EDR DIN Rail Power Supply MP3924 EDR-120-48 is a reliable power supply that delivers 120W of power with an output voltage of 48V and a current of 2.5A. Its robust construction and Short Circuit, Overload, voltage, and temperature built-in protections make it an ideal choice for interior and cabinet installation.
Features:
• Universal AC input / Full range
• Cooling by free air convection
• Installable on DIN rail TS-35/7.5 or 15
• 100% full load burn-in test
• Low cost
• 3 year warranty
Features:
Model Number: EDR-120-48
Output Voltage: 48VDC
Output Current: 2.5A
Ripple & Noise: 150mV
Efficiency: 88.5%
Input Voltage: 90~264VAC, 127~370VDC
Frequency Range: 47~63Hz
In Rush Current: 35A @ 230VAC
DIN Rail Compatibility: TS-35/7.5 or 15 mountable
Dimensions: 125.2(L) x 40(W) x 113.5(D)mm
Specifications:
| Packaged Volume : 1.41l |
| Packaged Weight : 0.54kg |
| Packaged Length : 15cm |
| Packaged Width : 6.5cm |
| Packaged Height : 14.5cm |
