Description
The Perfect Solution for Digital Mixing
Revolutionizing Live Entertainment with the BEHRINGER SD16
Digital mixing has transformed the live-entertainment production workflow, offering superior flexibility and convenience. The BEHRINGER SD16 Stage Box Interface is an ideal solution for connecting your onstage talent with your Front of House (FOH) console, delivering exceptional performance at an affordable price. Featuring 16 MIDAS-designed remote-controllable mic preamps, 8 balanced analog XLR returns, and an integrated 4-port ULTRANET distribution hub, the SD16 offers seamless connectivity and flexibility for any live event.
Ultra-Efficient Setup with Shielded CAT5e Cable
The BEHRINGER SD16 makes setup easy with a single shielded CAT5e cable connection, allowing up to 330 feet (100 meters) of distance per stage box. This streamlined design eliminates the need for bulky cabling, reducing clutter and ensuring a neat stage setup. If more inputs are required, you can cascade up to three SD16 Stage Boxes via the built-in AES50 ports, providing up to 48 inputs and 24 balanced XLR outputs. This makes it the perfect choice for venues or events requiring extensive audio input options.
Key Features of the BEHRINGER SD16
-
16 MIDAS-designed, fully programmable mic preamps: Offering high-quality, audiophile-grade sound.
-
8 balanced analog XLR outputs: For seamless integration into your setup.
-
AES50 network ports: Featuring KLARK TEKNIK’s SuperMAC networking for ultra-low latency and jitter.
-
4-port ULTRANET distribution hub: Connect up to four BEHRINGER P16-M personal monitoring mixers without additional hardware.
-
Compact and road-ready design: Rugged steel chassis with protective bumpers for easy transportation and durability.
-
Shielded CAT5e cable operation: Allows remote operation from up to 330 ft / 100 m away.
-
USB connector: For system updates via PC, ensuring your equipment stays up to date.
-
Dual AES50 ports: Enables cascading multiple units for increased inputs and outputs.
Simplified Audio Solutions with ULTRANET and Hi-Z Compatibility
The SD16 Stage Box is designed for easy integration with BEHRINGER's ULTRANET system, providing power and 16 audio channels to up to four P16-M personal monitor mixers, all via affordable shielded CAT5e cabling. No additional hardware is needed for this setup, making it a cost-effective and streamlined solution. The SD16 also features two Hi-Z compatible inputs, allowing you to connect instruments like keyboards, acoustic guitars, and bass guitars directly without the need for a DI box.
Expand Your Audio Capabilities
The BEHRINGER SD16 is perfect for larger setups where you need to keep cable runs short and tidy. By positioning an SD16 at the front of the stage and another at the rear (such as behind the drum riser), you gain an additional 16 inputs for instruments like drum and guitar/bass amps. This versatile design allows you to build a comprehensive and efficient stage audio system with minimal effort.
Specifications of the BEHRINGER SD16 Stage Box Interface
-
16 MIDAS-designed mic preamps: Fully programmable and remote-controllable for precise sound quality.
-
8 analog XLR outputs: Servo-balanced for seamless output.
-
AES50 network ports: Featuring KLARK TEKNIK’s SuperMAC technology for low latency.
-
ULTRANET hub: Power and audio distribution for up to four P16-M personal monitor mixers.
-
Hi-Z inputs: Two inputs for connecting instruments without DI boxes.
-
Dual AES50 ports: Cascade up to three SD16 units for expanded inputs and outputs.
-
USB port: For easy system updates.
-
Chassis: Ultra-compact, all-steel with protective bumpers.
Designed for Durability and Performance
The BEHRINGER SD16 Stage Box is engineered with durability in mind, featuring a roadworthy all-steel chassis that can withstand the rigors of live performance environments. Whether you're touring or setting up in a venue, the SD16 is built to last. Rack ears and protective bumpers are included, making it easy to integrate into mobile or installed setups.
Don't miss out!
The BEHRINGER SD16 Stage Box Interface is an essential tool for live sound engineers seeking high-quality audio, flexibility, and ease of setup. With its cutting-edge technology, remote controllability, and ability to expand your inputs and outputs, the SD16 makes managing complex live performances simpler than ever. Whether you're using it as part of a complete X32 system or integrating it with your existing setup, the SD16 delivers superior performance in a compact and rugged design.
